| Casing Material | : | BRONZE |
| Discharge Head | : | 0 TO 10 FT |
| Discharge Size | : | 1-1/2 INCH |
| End Connection | : | 1-1/2 INCH FLANGED X 1-1/2 INCH FLANGED |
| Flow Rate | : | 0 TO 50 GPM |
| Impeller Design | : | DYNAMICALLY BALANCED, ONE PIECE |
| Impeller Material | : | BRONZE |
| Inclusions/Features | : | DEPENDABLE-QUIET OPERATION, OIL SATURATED FELT PAD LUBRICATION SYSTEM, PROVEN PERFORMANCE, RUGGED BRONZE SLEEVE BEARING ASSEMBLY |
| Input Supply Rating | : | 115 V 1 PHASE 60 HZ |
| Motor Type | : | RUGGED |
| OPTIONS | : | CAST IRON FLANGE, SHUT OFF FLANGE |
| Overall Dimensions | : | 16-1/4 INCH L X 10-1/4 INCH H |
| Pressure Rating | : | 125 PSI |
| Shaft Material | : | STAINLESS STEEL |
| Speed Rating | : | 1725 RPM |
| Suction Size | : | 1-1/2 INCH |
| Temperature Rating | : | 200 DEG F CONTINUOUS, 240 DEG F INTERMITTANT |
BRAZED PLATE TYPE; 316L STAINLESS STEEL (PLATE), COPPER (BRAZE) MATERIAL; 1 INCH MALE THREADED SIZE; UL (CANADA AND US), ASME, CRN, TUV APPLICABLE STANDARD; HEAT EXCHANGER; DOMESTIC HOT WATER, IN-FLOOR RADIANT HEATING, SNOW-MELT SYSTEM USED ON ITEM; PHYSICAL DIMENSION 12.2'' LENGTH X 4.9'' WIDTH X 3.7'' DEPTH; WORKING TEMPERATURE -425 TO 350 DEG F; MAXIMUM WORKING PRESSURE 450 PSI; WEIGHT 14.6 LB; WARRANTY 18 MONTHS FROM THE DATE OF MANUFACTURE, 1 YEAR FROM DATE OF INSTALLATION; TFP MODEL
- 16-1/4 INCH L X 10-1/4 INCH H OVERALL DIMENSIONS; 115 V 1 PHASE 60 HZ INPUT SUPPLY RATING; 0 TO 50 GPM FLOW RATE; COMMERCIAL HYDRONIC SYSTEM, DOMESTIC, RESIDENTIAL, HEATED/CHILLED WATER, ZONING APPLICATION
