Southwire® 47160907 Thermostat Cable, 150 V, 8-Conductor, 18 AWG Conductor, Solid, Bare Copper Conductor, 250 ft L
Southwire® 47160907 Thermostat Cable, 150 V, 8-Conductor, 18 AWG Conductor, Solid, Bare Copper Conductor, 250 ft L

Southwire® 47160907 Thermostat Cable, 150 V, 8-Conductor, 18 AWG Conductor, Solid, Bare Copper Conductor, 250 ft L

Southwire® 47160907 Thermostat Cable, 150 V, 8-Conductor, 18 AWG Conductor, Solid, Bare Copper Conductor, 250 ft L

Brand: Southwire®
Part #: 80726
Customer Part #:
Additional Information      :      General Purpose Rated
Capacitance      :      22.8 pF/ft
Conductor Material      :      Bare Copper
Conductor Size      :      18 AWG
Conductor Type      :      Solid
Insulation Material      :      Polypropylene
Insulation Thickness      :      0.005 in
Jacket Color      :      Brown
Jacket Material      :      PVC
Jacket Thickness      :      0.018 in
Length      :      250 ft
Number of Conductors      :      8
Outside Diameter      :      0.205 in
Resistance      :      6.52 Ohm/1000 ft
Solid/Stranded      :      Solid
Voltage Rating      :      150 V

Southwire® Thermostat Cable, 150 V, 8 Conductors, Bare Copper Conductor, Solid Conductor, 18 AWG Conductor, 0.205 in Outside Diameter, 250 ft Length, 0.005 in Insulation Thickness, 0.018 in Jacket Thickness, Solid, 6.52 Ohm/1000 ft Resistance, 22.8 pF/ft, Polypropylene Insulation, PVC Jacket, Brown Jacket, Additional Information: General Purpose Rated

  • Bare Copper conductors for excellent conductivity and low voltage drop
  • Durable rip cord for efficient jacket stripping and removal
  • Sequential length marking for easy tracking of usage
  • Specification Sheet https://assets.unilogcorp.com/267/ITEM/DOC/Southwire_47105807_Specification_Sheet.pdf
