Packard PRCF Series PRCF70A Motor Single Run Capacitor, MFD Rating: 70 uF, 440 VAC, Round, 2 in Dia, 4-3/4 in H
Packard PRCF Series PRCF70A Motor Single Run Capacitor, MFD Rating: 70 uF, 440 VAC, Round, 2 in Dia, 4-3/4 in H
Packard PRCF Series PRCF70A Motor Single Run Capacitor, MFD Rating: 70 uF, 440 VAC, Round, 2 in Dia, 4-3/4 in H
Packard PRCF Series PRCF70A Motor Single Run Capacitor, MFD Rating: 70 uF, 440 VAC, Round, 2 in Dia, 4-3/4 in H
Packard PRCF Series PRCF70A Motor Single Run Capacitor, MFD Rating: 70 uF, 440 VAC, Round, 2 in Dia, 4-3/4 in H

Packard PRCF Series PRCF70A Motor Single Run Capacitor, MFD Rating: 70 uF, 440 VAC, Round, 2 in Dia, 4-3/4 in H

Packard PRCF Series PRCF70A Motor Single Run Capacitor, MFD Rating: 70 uF, 440 VAC, Round, 2 in Dia, 4-3/4 in H

Brand: Packard
Part #: 43814
Customer Part #:
Average Life      :      60000 hr
Case Material      :      Aluminum
Diameter      :      2 in
Frequency Rating      :      50/60 Hz
Height      :      4-3/4 in
MFD Rating      :      70 uF
Series      :      PRCF Series
Shape      :      Round
Standard Tolerance      :      +/-10 %
Temperature Rating      :      -40 to 70 deg C
Voltage Rating      :      440 VAC

Packard Motor Single Run Capacitor, Series: PRCF Series, 70 uF MFD Rating, 440 VAC, 50/60 Hz, Round Shape, 60000 hr Average Life, +/-10 % Standard Tolerance, -40 to 70 deg C, Aluminum Case, 2 in Dia, 4-3/4 in Height

  • Manufactured using state of the art, metalized polypropylene film technology for self-restoration in the event of a breakdown
  • Eye catching packaging for retail environment
  • Contains metalized polypropylene film technology for self-restoration in the event of a breakdown
  • Sophisticated UL approved pressure sensitive interrupter to remove the capacitor from circuit at end of life
  • Patented, environmentally friendly oil prevents corrosion and aids in optimum heat transfer
  • Aluminum cans filled with soybean based oil
  • Made in U.S.A
