Mitsubishi Electric Trane® NTXAMT30A112AA Multi-Position Air Handler, 875 cfm, 208/230 V, 4.13 A, 60 Hz, 1 ph-Phase
Mitsubishi Electric Trane® NTXAMT30A112AA Multi-Position Air Handler, 875 cfm, 208/230 V, 4.13 A, 60 Hz, 1 ph-Phase
Manufacturer: Mitsubishi Electric Trane HVAC US LLC
Brand: Mitsubishi Electric Trane®
Part #: 388413
MPN: NTXAMT30A112AA
Customer Part #:
Min. Order Qty: 1
Login for Availability
Login for Price
| Amperage Rating | : | 4.13 A |
| CFM Rating | : | 875 cfm |
| Compressor Type | : | Scroll |
| Connection Size | : | 3/4 in |
| Connection Type | : | Flared |
| Cooling Capacity | : | 13400 to 27000 Btu/hr |
| Dimensions | : | 43-3/4 in H x 21 in W x 21-5/8 in D |
| EER Rating | : | 9 |
| Finish | : | Hot-Dipped Coated |
| Frequency Rating | : | 60 Hz |
| Heating Capacity | : | 13000 to 34000 Btu/hr |
| Liquid Line Size | : | 3/8 in |
| Material | : | Steel |
| Motor Type | : | ECM |
| Phase | : | 1 ph |
| Pressure Rating | : | 0.3 in-WG, 0.5 in-WG, 0.8 in-WG |
| Refrigerant Type | : | R-410A |
| SEER Rating | : | 15.2 |
| Sound Level | : | 41 dBA |
| Suction Line Size | : | 5/8 in |
| Temperature Rating | : | 68 to 90 deg F Cooling, 59 to 77 deg F Heating |
| Voltage Rating | : | 208/230 V |
Mitsubishi Electric Trane® Multi-Position Air Handler, 13400 to 27000 Btu/hr Cooling Capacity, 13000 to 34000 Btu/hr Heating, 208/230 V, 4.13 A, 60 Hz, 1 ph Phase, Scroll Compressor, 875 cfm, 9 EER Rating, 15.2 SEER, Flared Connection, R-410A Refrigerant, 41 dBA Sound Level, 3/4 in Connection, 3/8 in Liquid Line, 5/8 in Suction Line, ECM Motor, 0.3 in-WG, 0.5 in-WG, 0.8 in-WG, Steel, Finish: Hot-Dipped Coated, 68 to 90 deg F Cooling, 59 to 77 deg F Heating, 43-3/4 in H x 21 in W x 21-5/8 in D
- Ducted air handler provides a solution to cool and heat large zones
- Highly effi cient totally enclosed ECM motor
- Selectable external static pressure - 0.30, 0.50 and 0.80 in.WG with 3 fan speeds at each static setting
- 1 inch R4.2 fi berglass free insulation reduces condensation and boosts effi ciency
- Positive pressure cabinet with air leakage of less than 2.0% at 1.0 In.WG (Tested per ASHRAE Standard 193)
- Unique blow through design allows simple coil cleaning when the blower is removed
- Multi-position installation - horizontal (left or right), vertical (up or down)
- Optional electric heat kit for additional heat capacity
- Optional humidifi er control and ERV control
- Built-in humidifi er control, ERV control and auxiliary heat control
- Optional downfl ow kit
- Multiple control options available - kumo cloud® smart device app for remote access
- Third-party interface options
- Wired or wireless controllers
