Mars 833 Series 83316 Fused Pullout Disconnect, 30 A, 240 V, Fused, NEMA 3R, Surface Mount, Steel, Gray

Additional Information	:	9 in H, 1 ph
Amperage Rating	:	30 A
Enclosure Type	:	NEMA 3R
Fusible/Non-Fusible	:	Fused
Housing Color	:	Gray
Housing Material	:	Steel
Mounting Type	:	Surface Mount
Overall Depth	:	2-3/4 "
Overall Length	:	9 "
Overall Width	:	5 "
Series	:	833 Series
Suitable For Use With	:	Air Conditioner Disconnects
Voltage Rating	:	240 V

Mars Fused Pullout Disconnect, Model: 833 Series, 30 A, 240 V, Fused, NEMA 3R, Surface Mount, Steel, Gray, 5" Overall Width, 2-3/4" Overall Depth, 9" Overall Length

Provides a fused disconnecting means for air conditioning equipment.Rated for 30 Amps and 240 Volts, single phase.Features a front-open pullout design for easy access.Housed in a durable steel enclosure with a NEMA 3R rainproof rating for outdoor use.Rated for 10,000 amp Short Circuit Current Rating (SCCR).UL and cUL listed for safety assurance.
