Resideo T6 Pro TH6210U2001/U Programmable Thermostat, 7 Day, 5-1-1 Day, 5-2 Day Or Non-Programmable Programmability, 2 H / 1 C (Heat Pump), 1 H / 1 C (Conventional), Auto, Manual, Wall Mount (UWP Mount), Wired / Lead Wires, 20-30 VAC, Dual Powered
Resideo T6 Pro TH6210U2001/U Programmable Thermostat, 7 Day, 5-1-1 Day, 5-2 Day Or Non-Programmable Programmability, 2 H / 1 C (Heat Pump), 1 H / 1 C (Conventional), Auto, Manual, Wall Mount (UWP Mount), Wired / Lead Wires, 20-30 VAC, Dual Powered
| Accuracy | : | ± 1 °F |
| Amperage Rating | : | 0.02-1.0 A (Running) |
| Battery Size | : | AA |
| Battery Type | : | AA Alkaline |
| Changeover | : | Auto, Manual |
| Connection Type | : | Wired / Lead Wires |
| Contact Rating | : | 1.0 A (20-30 VAC) |
| Control Range | : | 40 °F-90 °F (Heat), 50 °F-99 °F (Cool) |
| Cool Current | : | 0.02-1.0 A (Y/Y2 Terminals) |
| Dehumidification | : | No |
| Differential Temperature | : | ± 1 °F, 1-1.5 °F (Multistage Only) |
| Display Type | : | LCD (Backlit) |
| Electrical Connection | : | UWP Mounting System |
| Fan Current | : | 0.02-0.5 A |
| Frequency Rating | : | 50 Hz, 60 Hz |
| Heat Current | : | 0.02-1.0 A (W/W2 Terminals), 0.02-0.5 A (E Terminal) |
| Humidity Rating | : | 5-90% RH (Non-Condensing) |
| Material | : | Plastic |
| Model | : | TH6210U2001/U |
| Mounting Type | : | Wall Mount (UWP Mount) |
| Power Rating | : | 1.0 VA (Backlight On) |
| Power Source | : | Dual Powered |
| Programmability | : | 7 Day, 5-1-1 Day, 5-2 Day or Non-Programmable |
| Sensing Element | : | Thermistor |
| Series | : | T6 Pro |
| Stages | : | 2 H / 1 C (Heat Pump), 1 H / 1 C (Conventional) |
| Switch Position | : | HEAT-OFF-COOL-AUTO-EMERGENCY-HEAT (System) |
| Switch Type | : | Relay |
| Temperature Rating | : | 37-102 °F |
| Temperature Settings | : | 40°F - 90°F (Heat), 50°F - 99°F (Cool) |
| Terminal Designation | : | R, RC, C, W, O/B, W2-AUX, E, Y, Y2, G, L/A, K, S, S |
| VA Rating | : | 1 VA (Backlight On) |
| Voltage Rating | : | 20-30 VAC |
Resideo Programmable Thermostat, Model: T6 Pro, 7 Day, 5-1-1 Day, 5-2 Day Or Non-Programmable Programmability, 2 H / 1 C (Heat Pump), 1 H / 1 C (Conventional), Auto, Manual, Wall Mount (UWP Mount), Wired / Lead Wires, 20-30 VAC, Dual Powered, LCD (Backlit), 40°F - 90°F (Heat), 50°F - 99°F (Cool), UWP Mounting System, R, RC, C, W, O/B, W2-AUX, E, Y, Y2, G, L/A, K, S, S Terminal Designation, 1 VA (Backlight On), 37-102 °F, ± 1 °F, ± 1 °F, 1-1.5 °F (Multistage Only), Thermistor, 5-90% RH (Non-Condensing), No Dehumidification, White, 4.06" H x 4.06" W x 1.09" D Dimensions, Plastic, AA Alkaline Battery, ≤1.0 A (20-30 VAC), 0.02-1.0 A (Running), 50 Hz, 60 Hz
