Resideo Genesis 47130307 Thermostat Cable, 18 AWG, 5 Conductors, 250' Length, Solid, Bare Copper, 300 V (Max), -4-140 °F

Capacitance	:	22.8 pF/ft
Conductor Material	:	Bare Copper
Conductor Size	:	18 AWG
Conductor Type	:	Solid
End Type	:	Bare Wire
Impedance	:	100 Ohms
Insulation Color	:	Red, White, Green, Blue, Yellow
Insulation Material	:	Polypropylene
Insulation Thickness	:	0.006 "
Jacket Color	:	Brown
Jacket Material	:	PVC
Jacket Thickness	:	0.015 "
Lay Length	:	3-1/2 "
Length	:	250 '
Number of Conductors	:	5
Outside Diameter	:	0.172 "
Package Type	:	Reel
Resistance	:	6.5 Ohms (Per 1000 Ft @ 20°C)
Series	:	Genesis
Solid/Stranded	:	Solid
Temperature Rating	:	-4-140 °F
Voltage Rating	:	300 V (Max)

Resideo Thermostat Cable, Model: Genesis, 18 AWG, 5 Conductors, 250' Length, Solid, Bare Copper, 300 V (Max), -4-140 °F, Polypropylene Insulation, PVC Jacket, 0.015" (Nominal) Jacket Thickness, 0.006" (Nominal) Insulation Thickness, Bare Wire, Brown, Red, White, Green, Blue, Yellow Insulation Color, 0.172" (Nominal) Outside Diameter, 3-1/2" (Nominal) Lay Length, Reel, 6.5 Ohms (Per 1000 Ft @ 20°C), 100 Ohms (Nominal), 22.8 Pf/Ft

Features five 18 AWG solid bare copper conductors for reliable signal transmission.Durable brown PVC jacket provides protection and is sunlight resistant.Polypropylene insulation ensures proper signal isolation between conductors.CL2 rated for use in general-purpose, low-voltage thermostat wiring applications.Rated for operating temperatures from -4°F to 140°F (-20°C to 60°C).Comes in a convenient 250 ft reel package.Includes a ripcord for easier jacket stripping during installation.Meets UL Standard 13 and NEC Article 725 requirements.
