| AFUE Rating | : | 98 % |
| Amperage Rating | : | 14.1 A |
| Blower Size | : | 11 in Dia x 10 in W |
| CFM Rating | : | 2000 cfm |
| Cabinet Dimensions | : | 35 in H x 21 in W x 29-1/2 in D |
| Configuration | : | Down Flow, Horizontal, Up Flow |
| Connection Size | : | 1/2 in |
| Connection Type | : | NPT |
| Frequency Rating | : | 60 Hz |
| HP Rating | : | 1 hp |
| Ignition System | : | Hot Surface |
| Ignition Type | : | Silicon Nitride |
| Input BTU Rating | : | 80000 Btu/hr |
| Material | : | Steel |
| Model | : | G97CMN |
| Motor Type | : | ECM |
| Number of Burners | : | 4 |
| Output BTU Rating | : | 78000 Btu/hr |
| Phase | : | 1 ph |
| Rotational Speed | : | 1300 rpm |
| Temperature Rise | : | 40 to 70 deg F |
| Tonnage | : | 5.5 ton |
| Transformer Rating | : | 40 VA |
| Vent, Ducted or Ductless | : | Vent |
| Voltage Rating | : | 115 V |
Enjoy ultimate comfort even in the coldest weather with our highest efficiency gas furnace product. It features modulating gas heat performance that delivers incredible temperature control and quiet performance. The variable-speed blower also means you'll enjoy better summer dehumidification and a possible SEER boost as your furnace works with your cooling unit to help pull moisture out of the air. Pair it with a compatible air conditioner for full functionality and a full communicating system using the Ion™ Black System Control.
HEIL® Ion™ Gas Furnace, Model: G97CMN, Input BTU Rating: 80000 Btu/hr, Output BTU Rating: 78000 Btu/hr, 115 V, 14.1 A, 2000 cfm, 1 hp, 98 % AFUE Rating, 1 ph Phase, 60 Hz, Down Flow, Horizontal, Up Flow, NPT Connection, 1/2 in Connection, 4 Burners, Blower Size: 11 in Dia x 10 in W, 35 in H x 21 in W x 29-1/2 in D Cabinet, ECM Motor, 1300 rpm Rotational Speed, Vent, Ducted or Ductless: Vent, Tonnage: 5.5 ton, 40 VA Transformer, Hot Surface Ignition System, Silicon Nitride Ignition, Steel, 40 to 70 deg F Temperature Rise
- Variable-speed blower motor and modulating gas valve provide our ultimate levels of even temperature control and comfort
- Dual fuel capable with a compatible heat pump and thermostat for energy-saving heating performance
- As a modulating furnace, it operates at lower stages most of the time to save energy, smoothly ramping up the heat as temperatures drop
- Fully insulated cabinet keeps the heat moving to your ductwork
- Air purifier and humidifier compatible
- Wi-Fi® enabled remote access with the Ion™ Black System Control
- 10-Year No Hassle Replacement™ Limited Warranty
- 10-Year Parts Limited Warranty upon timely registration
- Lifetime Heat Exchanger Limited Warranty upon timely registration
- High efficiency variable-speed, constant airflow ECM blower motor
- Variable-speed induced draft combustion motor
- Modulating gas valve with range of 40%-100% capacity
- RPJ® (Rigid Press Joint) primary heat exchanger, stainless steel secondary heat exchanger
- Reliable direct gas ignition with silicon nitride ignitor
- High temperature limit control prevents overheating
- Solid, pre-painted steel insulated cabinet with tight fit door latch system
- Sound-reducing features: soft mounted blower and inducer motor
- Compatible thermostat: Ion™ Black System Control for full function and efficiency capability, Wi-Fi® remote access convenience and intelligent diagnostics
- Heating capacity: 60,000-120,000 BTUh
