| Average Arrestance | : | 93 % |
| Depth | : | 1 in |
| Filter Efficiency | : | 30 to 35 % |
| Height | : | 53-3/8 in |
| MERV | : | 8 |
| Media Material | : | Non-Woven Synthetic |
| Pleats per Linear Feet | : | 13 |
| Rated Velocity | : | 300/500 fpm |
| Series | : | 80055D Series |
| Temperature Rating | : | 180 deg F |
| Width | : | 13-3/8 in |
Flanders has LED the world in filter media development and the application of high-efficiency filtration for over 60 years. Originally introduced in 2004, the industry's first MERV 8 3 8 filter operating solely on mechanical means has now been improved since 2004, other manufacturers have altered media blends to meet the LEED® and market driven demand for non-electret MERV 8 3 8 filters. This has LED to pressure drop increases in their filters of 25% or more, utilizing a unique new fiber technology, our research and development team has now achieved multiple goals of maintaining MERV 8 3 8A performance at a resistance that is 40% lower than competition. At the same time, the LPD's dust holding capacity remains the highest in the industry.
Flanders® Pleated Air Filter, 80055D Series, Non-Woven Synthetic Media, 13-3/8 in Width, 53-3/8 in Height, 1 in Depth, 8 MERV, 30 to 35 % Filter Efficiency, 13 Pleats per Linear Feet, 300/500 fpm Rated Velocity, 93 % Average Arrestance, 180 deg F
- Media is made of 100% synthetic non-woven proprietary media that can be recycled
- The media is supported by an expanded metal continuously laminated on the air leaving side to provide pleat stability while eliminating flutter
- Pleat design is a V-pleat that aids in pressure drop while reducing energy cost and allowing total media usage and provides maximum airflow and dust holding capacity
- Frame is a two piece construction, made of a heavy-duty 24 point moisture-resistant material
- Diagonal and horizontal support members are bonded to the media on both sides
- Highest dust holding capacity and lowest pressure drop-in the industry
- 40% low pressure drop
