Sanhua DTG Series FD-307-S Filter Drier, ODF Connection, 7/8" Connection Size, 30 Cu. In., 18.4 Tons (R-410A), 18.2 Tons (R-22), 20 Microns Micron Rating, R-22, R-134A, R-404A, R-407C, R-410A, R-507, 714.7 PSI

Connection Type	:	ODF
Domestic/Import	:	Import
Finish	:	Painted
Flow Capacity	:	18.4 tons (R-410A), 18.2 tons (R-22)
Material	:	Steel (Casing), Molecular Sieve/Active Alumina (Desiccant Blend)
Micron Rating	:	20 microns
Model	:	FD-307-S
Pressure Rating	:	714.7 PSI
Refrigerant Type	:	R-22, R-134A, R-404A, R-407C, R-410A, R-507
Series	:	DTG Series
Size	:	7/8 "
Suitable For Use With	:	All Common HCFC and HFC Refrigerants
Temperature Rating	:	-22-131 °F (Ambient), -22-248 °F (Medium Ts)
Volume	:	30 cu. in.

Sanhua Filter Drier, Model: DTG Series, ODF Connection, 7/8" Connection Size, 30 Cu. In., 18.4 Tons (R-410A), 18.2 Tons (R-22), 20 Microns Micron Rating, R-22, R-134A, R-404A, R-407C, R-410A, R-507, 714.7 PSI, -22-131 °F (Ambient), -22-248 °F (Medium Ts), Steel (Casing), Molecular Sieve/Active Alumina (Desiccant Blend), Painted, Import

Protects systems by absorbing moisture and acid with an 80% molecular sieve/20% activated alumina core.Provides 20-micron filtration to remove solid particle contamination.Features durable 7/8" ODF solder connections.Compatible with common HCFC and HFC refrigerants including R-22, R-134a, R-404A, R-407C, R-410A, and R-507.UL/CSA listed for safety and reliability.Rated for a maximum operating pressure of 714.7 PSI.Suitable for fluid temperatures ranging from -22°F to +250°F.
