Bosch Greensource SM Rev A/B SM024-1VTC-FRTADB-XMGXXXXXD7XXXX4XXXXSBA Water Source Heat Pump, 2 Tons, R-410A, Vertical, Upflow, Left Return, Desuperheater, 208/230 V, 17.4 EER (WLHP), 26.5 EER (GWHP), 19.9 EER (GLHP), 3/4" FPT (Non-Swivel) Connection, 1-Phase
Bosch Greensource SM Rev A/B SM024-1VTC-FRTADB-XMGXXXXXD7XXXX4XXXXSBA Water Source Heat Pump, 2 Tons, R-410A, Vertical, Upflow, Left Return, Desuperheater, 208/230 V, 17.4 EER (WLHP), 26.5 EER (GWHP), 19.9 EER (GLHP), 3/4" FPT (Non-Swivel) Connection, 1-Phase

Bosch Greensource SM Rev A/B SM024-1VTC-FRTADB-XMGXXXXXD7XXXX4XXXXSBA Water Source Heat Pump, 2 Tons, R-410A, Vertical, Upflow, Left Return, Desuperheater, 208/230 V, 17.4 EER (WLHP), 26.5 EER (GWHP), 19.9 EER (GLHP), 3/4" FPT (Non-Swivel) Connection, 1-Phase

Bosch Greensource SM Rev A/B SM024-1VTC-FRTADB-XMGXXXXXD7XXXX4XXXXSBA Water Source Heat Pump, 2 Tons, R-410A, Vertical, Upflow, Left Return, Desuperheater, 208/230 V, 17.4 EER (WLHP), 26.5 EER (GWHP), 19.9 EER (GLHP), 3/4" FPT (Non-Swivel) Connection, 1-Phase

Manufacturer: Robert Bosch
Brand: BOSCH
Part #: 384129
MPN: 7-735-066-001
Customer Part #:
Min. Order Qty: 1
Login for Availability
Login for Price
Amperage Rating      :      2.8 A (FLA, Fan), 11.7 A (RLA, Compressor), 17.4 A (MCA)
BTU Rating      :      24,000 BTU/hr
Blower Size      :      9" Diam x 7" W
CFM Rating      :      800 CFM
Coil Rating      :      2 Tons
Color      :      White
Compressor Type      :      Scroll
Configuration      :      Vertical, Upflow, Left Return, Desuperheater
Connection Type      :      3/4" FPT (Non-Swivel)
Dimensions      :      44-3/5" H x 24" W x 27-2/5" D
Domestic/Import      :      Domestic
Drive Type      :      ECM Constant Airflow
EER Rating      :      17.4 EER (WLHP), 26.5 EER (GWHP), 19.9 EER (GLHP)
Filter Size      :      24" L x 24" H x 2" D
Finish      :      White Pre-Painted
Frequency Rating      :      60 Hz
Fuse Rating      :      25 A
HP Rating      :      1/3 HP (Fan Motor)
Material      :      Sheet Metal (Cabinet), Tin-Plated (Evaporator Coil), Stainless Steel (Drain Pan)
Model      :      SM024-1VTC-FRTADB-XMGXXXXXD7XXXX4XXXXSBA
Mounting Type      :      Vertical Upflow
Number of Stages      :      1
Phase      :      1
Pressure Rating      :      464.7 PSI (Max Water Working)
Refrigerant Type      :      R-410A
Series      :      Greensource SM Rev A/B
Sound Level      :      52 dBA
Temperature Rating      :      50-110 °F (Entering Water)
Tonnage      :      2 tons
Voltage Rating      :      208/230 V

Bosch Water Source Heat Pump, Model: Greensource SM Rev A/B, 2 Tons, R-410A, Vertical, Upflow, Left Return, Desuperheater, 208/230 V, 17.4 EER (WLHP), 26.5 EER (GWHP), 19.9 EER (GLHP), 3/4" FPT (Non-Swivel) Connection, 1-Phase, 44-3/5" H x 24" W x 27-2/5" D Dimensions, 800 CFM, ECM Constant Airflow, Scroll, 9" Diam x 7" W Blower Size, 1/3 HP (Fan Motor), Sheet Metal (Cabinet), Tin-Plated (Evaporator Coil), Stainless Steel (Drain Pan), Vertical Upflow, 24" L x 24" H x 2" D Filter Size, ≥52 dBA, 1 Stage, 24,000 BTU/hr, 2.8 A (FLA, Fan), 11.7 A (RLA, Compressor), 17.4 A (MCA), Domestic, 464.7 PSI (Max Water Working), 50-110 °F (Entering Water), 60 Hz, 25 A Fuse Rating

Achieves high efficiency ratings, including up to 26.5 EER (GWHP) and 4.9 COP (GWHP).Operates quietly with sound levels as low as 52 dBA using closed-cell foam insulation and a floating base pan.Features an ECM constant airflow motor for efficient and consistent comfort.Utilizes a reliable single-stage scroll compressor.Includes an integrated desuperheater for supplemental domestic hot water heating.Equipped with a durable tin-plated evaporator coil and a stainless steel drain pan for reliability and IAQ.Designed for easy service with front access to major components and an LCD diagnostic display.ENERGY STAR certified for ground water and ground loop applications.Backed by a 10-year limited parts and labor allowance warranty.
